In stock
$199.05
parameter
general indicators
Frequency Range:
TX: 156.025-162.000MHz
RX:156.025-162.025MHz
Frequency of use: INT, USA, CAN channels
Send type: 16K0G3E (FM)
Power supply: 13.8V DC standard (11.7V-15.9V DC)
Current Consumption:
TX (25W output): 5.5A (not greater than)
RX: 1.5A (not greater than)
Operating temperature: -20°C~60°C
Antenna impedance: 50Ω
Dimensions (excluding protruding parts): 153*67*133mm
Weight: about 790g
launch indicator
Output power: 25W (High power) 1W (Low power)
Modulation method: variable reactance
Frequency offset: ±5kHz
Frequency stability: ±5ppm
Spurious emissions:
Less than -70dBc(High power)
Less than -56dBc (Low power)
Adjacent channel power: greater than 70dB
Audio distortion: less than 10% (at 60% dev.)
Residual modulation: more than 40dB
Reception indicator
IF frequency:
1st: 21.7MHz
2nd: 450kHz
Sensitivity: -14dB μ nominal (at 12dB SINAD)
Static dry sensitivity: less than -10dBμ
Adjacent channel selectivity: 70dB typical
Spurious response: 70dB typical
Intermodulation: 70dB typical
Signal-to-noise ratio: More than 40dB
Audio output: 4.5W nominal I (10% distortion 4Ω load)
-
